Intel · 2015
Intel QMS180
The Intel QMS180 is a mobile chipset for LGA 1151 processors, released in 2015 on a 22 nm process with a 6 W TDP.
The Intel QMS180 is a mobile chipset designed for LGA 1151 processors, released in September 2015. It is built on a 22 nm process with a TDP of 6 W. The chipset supports DDR4-2133 memory up to 64 GB across two channels, without ECC support. It provides 20 PCIe 3.0 lanes, 6 SATA III ports, 10 USB 3.2 Gen 1 ports, and 14 USB 2.0 ports. Integrated Ethernet is available via an integrated MAC. It supports Intel Rapid Storage Technology and vPro, but does not support CPU or memory overclocking. The chipset is used in mobile platforms with FCBGA form factor.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform unverified | Mobile |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 20 |
| DMI version | 3.0 |
| Memory support unverified | DDR4-2133 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 6 |
| USB 3.2 Gen 2 ports unverified | 0 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Integrated Ethernet | Integrated MAC |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Supported form factors unverified | FCBGA |
| Release date | 2015-09-01 |
| Release year | 2015 |
| Launch MSRP | 47 USD |
| Notes | QMS180 is a mobile chipset; some specs inferred from Q170 desktop variant. |
