Intel QS67
The Intel QS67 is a mobile chipset for LGA 1155 processors, released in 2011.
The Intel QS67 is a mobile chipset designed for LGA 1155 socket processors, released on February 20, 2011. It is built on a 32 nm process with a TDP of 3.4 W. The chipset supports DDR3 memory with two channels and a maximum capacity of 16 GB, but does not support ECC memory. It provides 8 PCIe 2.0 lanes and uses DMI 2.0 for connection to the processor. Storage connectivity includes 6 SATA III ports, and it offers 14 USB 2.0 ports. The QS67 is intended for use with Intel's second-generation Core processors (Sandy Bridge) in mobile platforms.
Specifications
| Socket unverified | LGA 1155 |
|---|---|
| Platform unverified | Mobile |
| Process node unverified | 32 nm |
| TDP unverified | 3.4 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 6 |
| USB 2.0 ports unverified | 14 |
| Release date unverified | 2011-02-20 |
| Release year unverified | 2011 |
