Intel · 2012
Intel QS77
The Intel QS77 is a mobile chipset released in 2012, supporting DDR3 memory and featuring integrated SATA III and USB 3.0 connectivity.
The Intel QS77 is a mobile chipset introduced in 2012, designed for use with Intel's 3rd generation Core processors (Ivy Bridge) in BGA 1224 packages. It is built on a 22 nm process with a TDP of 3.6 W. The chipset provides 8 PCIe 2.0 lanes and supports dual-channel DDR3/L/-RS memory up to 16 GB at speeds of 1333/1600 MHz. It includes six SATA III ports, four USB 3.2 Gen 1 ports, and ten USB 2.0 ports. Features include Intel Rapid Storage Technology and vPro support. The QS77 communicates with the processor via DMI 2.0.
Specifications
| Socket unverified | BGA 1224 |
|---|---|
| Platform | Mobile |
| Process node unverified | 22 nm |
| TDP | 3.6 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3/L/-RS 1333/1600 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 4 |
| USB 2.0 ports | 10 |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| Release date unverified | 2012-04-08 |
| Release year | 2012 |
| Discontinued | Discontinued |
