Intel UM77
The Intel UM77 is a mobile chipset released in 2012, designed for low-power systems with a 3 W TDP and 22 nm process.
The Intel UM77 is a mobile chipset introduced on April 8, 2012, built on a 22 nm process with a thermal design power of 3 W. It uses a BGA socket and supports DDR3 and LPDDR3 memory with a maximum capacity of 16 GB across two channels. The chipset provides four PCIe 2.0 lanes and features DMI 2.0 for connection to the processor. It includes four SATA III ports, four USB 3.2 Gen 1 ports, and six USB 2.0 ports. Intel Rapid Storage Technology is supported. The UM77 is intended for use with compatible Intel mobile processors from the same era.
Specifications
| Socket unverified | BGA |
|---|---|
| Platform | Mobile |
| Process node unverified | 22 nm |
| TDP | 3 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 4 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3/LPDDR3 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports | 4 |
| USB 3.2 Gen 1 ports | 4 |
| USB 2.0 ports | 6 |
| Intel Rapid Storage Technology | Yes |
| Release date unverified | 2012-04-08 |
| Release year | 2012 |
