Intel · 2018
Intel Z390
The Intel Z390 is a desktop chipset for LGA 1151 sockets, released in 2018. It supports DDR4 memory and offers overclocking capabilities.
The Intel Z390 is a chipset designed for desktop platforms, released on October 8, 2018. It uses the LGA 1151 socket and has a TDP of 6 W. The chipset provides 24 PCIe 3.0 lanes and supports DMI 3.0. It features six SATA III ports, six USB 3.2 Gen 2 ports, ten USB 3.2 Gen 1 ports, and fourteen USB 2.0 ports. Integrated Ethernet MAC and Intel Wireless-AC MAC are included. It supports Intel Rapid Storage Technology, CPU overclocking, and memory overclocking via XMP/EXPO. ECC memory is not supported. The chipset is used with 8th and 9th generation Intel Core processors.
Specifications
| Socket | LGA 1151 |
|---|---|
| Platform | Desktop |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 24 |
| DMI version | 3.0 |
| Memory support | DDR4 |
| ECC memory support | No |
| SATA III ports | 6 |
| USB 3.2 Gen 2 ports | 6 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Integrated Ethernet | Integrated MAC |
| Integrated Wi-Fi | Intel Wireless-AC MAC |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking | Yes |
| Memory overclocking (XMP/EXPO) | Yes |
| Release date unverified | 2018-10-08 |
| Release year | 2018 |
