Intel Z490
The Intel Z490 is a desktop chipset for LGA 1200 sockets, released in Q2 2020. It supports DDR4 memory, PCIe 3.0, and CPU overclocking.
The Intel Z490 is a chipset designed for desktop platforms using the LGA 1200 socket, released in the second quarter of 2020. It has a TDP of 6 W and features 24 PCIe 3.0 lanes from the chipset, with a DMI 3.0 interface to the CPU. The chipset supports DDR4 memory but not ECC memory. It includes six SATA III ports, six USB 3.2 Gen 2 ports, ten USB 3.2 Gen 1 ports, and fourteen USB 2.0 ports. Integrated Ethernet is provided via an integrated MAC, and it supports Intel Wi-Fi 6 AX201. The Z490 enables CPU and memory overclocking (XMP/EXPO) and includes Intel Rapid Storage Technology. It is used with Intel Core processors of the 10th generation (Comet Lake) and has been discontinued.
Specifications
| Socket unverified | LGA 1200 |
|---|---|
| Platform | Desktop |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 24 |
| DMI version | 3.0 |
| Memory support unverified | DDR4 |
| ECC memory support | No |
| SATA III ports | 6 |
| USB4 ports unverified | 0 |
| USB 3.2 Gen 2x2 ports unverified | 0 |
| USB 3.2 Gen 2 ports | 6 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Integrated Ethernet | Integrated MAC |
| Integrated Wi-Fi | Intel Wi-Fi 6 AX201 |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking | Yes |
| Memory overclocking (XMP/EXPO) | Yes |
| Release date | 2020-Q2 |
| Release year | 2020 |
| Discontinued | Discontinued |
