X670E
The X670E is an AMD chipset for Socket AM5, released in 2022. It supports DDR5 memory, PCIe 5.0, and CPU/memory overclocking.
The X670E is a chipset for AMD Socket AM5 platforms, released on September 27, 2022. It is built on a 14 nm process and has a TDP of 14 W. The chipset provides 12 PCIe 5.0 lanes, 8 SATA III ports, and a DMI 4.0 interface to the CPU. It supports up to 192 GB of DDR5 memory across two channels, with ECC support and memory overclocking via XMP/EXPO. The X670E offers extensive USB connectivity: 2 USB 3.2 Gen 2x2 ports, 12 USB 3.2 Gen 2 ports, and 12 USB 2.0 ports. It does not include USB4 or Thunderbolt. Integrated Ethernet, Wi-Fi, and Bluetooth are optional. The chipset supports ATX, Micro-ATX, and Mini-ITX form factors. It is the successor to the X570 and was succeeded by the X870E.
Specifications
| Socket unverified | AM5 |
|---|---|
| Platform unverified | AMD Socket AM5 |
| Process node unverified | 14 nm |
| TDP unverified | 14 W |
| PCIe version unverified | 5.0 |
| Total PCIe lanes (chipset) unverified | 12 |
| DMI version unverified | 4.0 |
| Memory support unverified | DDR5 |
| Max memory unverified | 192 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | Yes |
| SATA III ports unverified | 8 |
| USB4 ports unverified | 0 |
| USB 3.2 Gen 2x2 ports unverified | 2 |
| USB 3.2 Gen 2 ports unverified | 12 |
| USB 3.2 Gen 1 ports unverified | 0 |
| USB 2.0 ports unverified | 12 |
| Thunderbolt support unverified | No |
| Integrated Ethernet unverified | Optional |
| Integrated Wi-Fi unverified | Optional |
| Integrated Bluetooth unverified | Optional |
| CPU overclocking unverified | Yes |
| Memory overclocking (XMP/EXPO) unverified | Yes |
| Supported form factors unverified | ATX, Micro-ATX, Mini-ITX |
| Release date unverified | 2022-09-27 |
| Release year unverified | 2022 |
| Successor unverified | X870E |
| Predecessor unverified | X570 |
