AMD · 2007
AMD FireGL V7700
The AMD FireGL V7700 is a professional graphics card released in 2007, based on the TeraScale 1 architecture with 320 shading units.
The AMD FireGL V7700 is a professional graphics card released in 2007. It is built on the TeraScale 1 architecture and uses the R670 GL GPU chip fabricated on a 55 nm process. The card features 320 shading units and a base clock of 775 MHz. It is equipped with 0.5 GB of GDDR4 memory on a 256-bit bus, providing a memory bandwidth of 72 GB/s. The card supports DirectX 10.1 and OpenGL 3.3, and connects via PCIe 2.0. It has a single DisplayPort output. The FireGL V7700 can perform double precision computation using the AMD Stream SDK.
Specifications
| Architecture unverified | TeraScale 1 |
|---|---|
| GPU chip unverified | R670 GL |
| Process node unverified | 55 nm |
| Shading units unverified | 320 |
| Base clock unverified | 775 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | GDDR4 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 72 GB/s |
| Bus interface unverified | PCIe 2.0 |
| Display outputs unverified | DisplayPort |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release year unverified | 2007 |
| Notes unverified | Can do double precision computation via the AMD Stream SDK. |
