AMD · 2006
AMD FireMV 2200 PCI
The AMD FireMV 2200 PCI is a professional graphics card released in 2006, based on the Rage 7 architecture and RV280 GL chip.
The AMD FireMV 2200 PCI is a professional graphics card released in January 2006. It is built on the Rage 7 architecture with the RV280 GL GPU manufactured on a 150 nm process. The card features 4 shading units, a base clock of 240 MHz, and 0.064 GB of DDR memory on a 64-bit bus, providing a memory bandwidth of 3.2 GB/s. It has a board power (TDP) of 15 W and connects via a PCI bus. Display output is through a DMS-59 connector supporting dual DVI-D. The card supports DirectX 8.1 and OpenGL 1.4.
Specifications
| Architecture unverified | Rage 7 |
|---|---|
| GPU chip unverified | RV280 GL |
| Process node unverified | 150 nm |
| Shading units unverified | 4 |
| Base clock unverified | 240 MHz |
| Memory size unverified | 0.064 GB |
| Memory type unverified | DDR |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 3.2 GB/s |
| Board power (TDP) unverified | 15 W |
| Bus interface unverified | PCI |
| Display outputs unverified | DMS-59 (dual DVI-D) |
| DirectX support unverified | 8.1 |
| OpenGL support unverified | 1.4 |
| Release date unverified | 2006-01 |
| Release year unverified | 2006 |
