AMD · 2010
AMD FirePro 3D V5800
The AMD FirePro 3D V5800 is a professional graphics card released in 2010, based on the TeraScale 2 architecture.
The AMD FirePro 3D V5800 is a professional graphics card released on April 26, 2010. It is built on the TeraScale 2 architecture and uses the Juniper XT GL (RV840) GPU chip manufactured on a 40 nm process. The card features 800 shading units, a base clock of 700 MHz, and 1 GB of GDDR5 memory on a 128-bit bus, providing a memory bandwidth of 64 GB/s. It supports DirectX 11.0 and OpenGL 4.3. The board has a TDP of 74 W and connects via PCIe 2.1 ×16. Additional features include UVD2, PowerPlay, and Eyefinity multi-display support.
Specifications
| Architecture unverified | TeraScale 2 |
|---|---|
| GPU chip unverified | Juniper XT GL (RV840) |
| Process node unverified | 40 nm |
| Shading units unverified | 800 |
| Base clock unverified | 700 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 64 GB/s |
| Board power (TDP) unverified | 74 W |
| Bus interface unverified | PCIe 2.1 ×16 |
| DirectX support unverified | 11.0 |
| OpenGL support unverified | 4.3 |
| Release date unverified | 2010-04-26 |
| Release year unverified | 2010 |
| Notes unverified | UVD2, PowerPlay, Eyefinity |
