AMD · 2014
AMD FirePro W9100
The AMD FirePro W9100 is a professional graphics card released in 2014, based on the GCN 2nd generation architecture with 16 GB of GDDR5 memory.
The AMD FirePro W9100 is a professional workstation graphics card launched on March 26, 2014. It is built on the GCN 2nd generation architecture using the Hawaii XT GPU on a 28 nm process. The card features 2816 shading units, a base clock of 930 MHz, and 16 GB of GDDR5 memory with a 512-bit bus, providing a memory bandwidth of 320 GB/s. It supports ECC RAM for error correction. The board power (TDP) is 275 W and it connects via PCIe 3.0 ×16. Display outputs include 6× Mini DisplayPort and an SDI-Link connector. The card supports DirectX 11.2b/12.0, Vulkan 1.0, and OpenGL 4.5. It is designed for professional applications requiring high compute performance and large memory capacity.
Specifications
| Architecture unverified | GCN 2nd gen |
|---|---|
| GPU chip unverified | Hawaii XT |
| Process node unverified | 28 nm |
| Shading units unverified | 2816 |
| Base clock unverified | 930 MHz |
| Memory size unverified | 16 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 512 bit |
| Memory bandwidth unverified | 320 GB/s |
| Board power (TDP) unverified | 275 W |
| Bus interface unverified | PCIe 3.0 ×16 |
| Display outputs unverified | 6× Mini DisplayPort, SDI-Link |
| DirectX support unverified | 11.2b/12.0 |
| Vulkan support unverified | 1.0 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2014-03-26 |
| Release year unverified | 2014 |
| Notes unverified | ECC RAM |
