AMD · 2005
AMD M26
The AMD M26 is a mobile graphics card released in March 2005, based on the R300 architecture with an RV410 GPU.
The AMD M26 is a mobile graphics card released in March 2005. It is based on the R300 architecture and uses the RV410 GPU manufactured on a 110 nm process. The card features 6 shading units, a base clock of 400 MHz, and 0.128 GB of memory. Memory options include DDR and GDDR3 types on a 128-bit bus, providing a memory bandwidth of 11.2 GB/s. It connects via a PCIe ×16 interface and supports DirectX 9.0b and OpenGL 2.0. Notable features include 3DC texture compression and dynamic lane count switching. The M26 is designed for use in laptops and other mobile systems.
Specifications
| Architecture unverified | R300 |
|---|---|
| GPU chip unverified | RV410 |
| Process node unverified | 110 nm |
| Shading units unverified | 6 |
| Base clock unverified | 400 MHz |
| Memory size unverified | 0.128 GB |
| Memory type unverified | DDR, GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 11.2 GB/s |
| Bus interface unverified | PCIe ×16 |
| DirectX support unverified | 9.0b |
| OpenGL support unverified | 2.0 |
| Release date unverified | 2005-03 |
| Release year unverified | 2005 |
| Notes unverified | 3DC, dynamic lane count switching |
