AMD · 2006
AMD M52
The AMD M52 is a mobile graphics chip released in 2006, based on the RV515 architecture and built on a 90 nm process.
The AMD M52 is a mobile graphics chip introduced on January 19, 2006. It is based on the RV515 architecture and manufactured on a 90 nm process. The chip features 4 shading units, a base clock of 350 MHz, and supports DirectX 9.0c and OpenGL 2.0. It is equipped with 0.128 GB of DDR or DDR2 memory on a 128-bit bus, providing a memory bandwidth of 8 GB/s. The M52 connects via a PCIe ×16 interface. It is designed for use in laptops and other mobile systems requiring basic 3D graphics capabilities.
Specifications
| Architecture unverified | RV515 |
|---|---|
| GPU chip unverified | M52 |
| Process node unverified | 90 nm |
| Shading units unverified | 4 |
| Base clock unverified | 350 MHz |
| Memory size unverified | 0.128 GB |
| Memory type unverified | DDR, DDR2 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 8 GB/s |
| Bus interface unverified | PCIe ×16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.0 |
| Release date unverified | 2006-01-19 |
| Release year unverified | 2006 |
