AMD M66
The AMD M66 is a mobile graphics chip released in 2006, based on the R500 architecture with a 90 nm process.
The AMD M66 (codenamed RV535) is a mobile graphics processing unit introduced in February 2006. It is built on the R500 architecture using a 90 nm fabrication process with strained silicon technology. The chip features 12 shading units, a base clock of 475 MHz, and supports DirectX 9.0c and OpenGL 2.0. Memory configurations include 256 MB of DDR2 or GDDR3 on a 128-bit bus, providing a bandwidth of 11.2 GB/s. The M66 connects via a PCIe ×16 interface and was designed for use in laptops and other mobile systems.
Specifications
| Architecture unverified | R500 |
|---|---|
| GPU chip unverified | RV535 |
| Process node unverified | 90 nm |
| Shading units unverified | 12 |
| Base clock unverified | 475 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | DDR2, GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 11.2 GB/s |
| Bus interface unverified | PCIe ×16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.0 |
| Release date unverified | 2006-02-01 |
| Release year unverified | 2006 |
| Notes unverified | strained silicon |
