AMD · 2008
AMD M86-XT
The AMD M86-XT is a graphics card released in 2008, based on the TeraScale architecture and RV635 GPU.
The AMD M86-XT is a graphics card released on January 7, 2008. It is built on the TeraScale architecture with the RV635 GPU manufactured on a 55 nm process. The card features 120 shading units, a base clock of 680 MHz, and 1 GB of memory. Memory options include DDR2, GDDR3, or GDDR4, all over a 128-bit bus, providing a memory bandwidth of 25.6 GB/s. It supports DirectX 10.1 and OpenGL 2.0 (3.3). The card has a TDP of 30 W and uses a PCIe ×16 2.0 interface. Additional features include UVD and PowerPlay 7.0.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV635 |
| Process node unverified | 55 nm |
| Shading units unverified | 120 |
| Base clock unverified | 680 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | DDR2, GDDR3, GDDR4 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 25.6 GB/s |
| Board power (TDP) unverified | 30 W |
| Bus interface unverified | PCIe ×16 2.0 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 2.0 (3.3) |
| Release date unverified | 2008-01-07 |
| Release year unverified | 2008 |
| Notes unverified | UVD, PowerPlay 7.0 |
