AMD · 2008
AMD M88-L/M88-LP
The AMD M88-L/M88-LP is a graphics card released in 2008, based on the RV670 architecture with 320 shading units and 0.5 GB GDDR3 memory.
The AMD M88-L/M88-LP is a graphics card released on June 4, 2008, built on the RV670 architecture using a 55 nm process node. It features 320 shading units running at a base clock of 580 MHz. The card is equipped with 0.5 GB of GDDR3 memory on a 256-bit bus, providing a memory bandwidth of 48.0 GB/s. It supports DirectX 10.1 and OpenGL 2.0 (3.3). The card uses a PCIe ×16 2.0 bus interface and includes UVD (Universal Video Decoder) and PowerPlay 7.0 power management technology. This graphics card is designed for use in desktop computers and is compatible with motherboards featuring a PCIe ×16 2.0 slot.
Specifications
| Architecture unverified | RV670 |
|---|---|
| GPU chip unverified | RV670 |
| Process node unverified | 55 nm |
| Shading units unverified | 320 |
| Base clock unverified | 580 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 48.0 GB/s |
| Bus interface unverified | PCIe ×16 2.0 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 2.0 (3.3) |
| Release date unverified | 2008-06-04 |
| Release year unverified | 2008 |
| Notes unverified | UVD, PowerPlay 7.0 |
