AMD · 2008
AMD M88-LXT
The AMD M88-LXT is a graphics card released in 2008, based on the TeraScale architecture and RV670 GPU.
The AMD M88-LXT is a graphics card released on June 4, 2008, using the TeraScale architecture. It features the RV670 GPU manufactured on a 55 nm process, with 320 shading units and a base clock of 660 MHz. The card has 0.5 GB of GDDR3 memory on a 256-bit bus, providing a memory bandwidth of 54.4 GB/s. It supports DirectX 10.1 and OpenGL 2.0 (3.3). With a TDP of 55 W, it connects via PCIe ×16 2.0. Additional features include UVD and PowerPlay 7.0.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV670 |
| Process node unverified | 55 nm |
| Shading units unverified | 320 |
| Base clock unverified | 660 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 54.4 GB/s |
| Board power (TDP) unverified | 55 W |
| Bus interface unverified | PCIe ×16 2.0 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 2.0 (3.3) |
| Release date unverified | 2008-06-04 |
| Release year unverified | 2008 |
| Notes unverified | UVD, PowerPlay 7.0 |
