AMD · 2009
AMD M96
The AMD M96 is a mobile graphics card from 2009, based on the TeraScale architecture and RV730 chip.
The AMD M96 is a mobile graphics card released on January 9, 2009. It is based on the TeraScale architecture with the RV730 GPU chip manufactured on a 55 nm process. The card features 320 shading units, a base clock of 500 MHz, and a boost clock of 550 MHz. It supports DirectX 10.1 and OpenGL 3.3. Memory options include 1 GB of DDR2, DDR3, or GDDR3 on a 128-bit bus, providing a memory bandwidth of 25.6 GB/s. The card uses a PCIe ×16 2.0 bus interface and includes UVD2 and PowerPlay 7.0 technologies.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV730 |
| Process node unverified | 55 nm |
| Shading units unverified | 320 |
| Base clock unverified | 500 MHz |
| Boost clock unverified | 550 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | DDR2, DDR3, GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 25.6 GB/s |
| Bus interface unverified | PCIe ×16 2.0 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2009-01-09 |
| Release year unverified | 2009 |
| Notes unverified | UVD2, PowerPlay 7.0 |
