AMD · 2009
AMD M97
The AMD M97 is a graphics card released in 2009, based on the TeraScale architecture and RV740 GPU.
The AMD M97 is a graphics card from 2009, built on the TeraScale architecture with the RV740 GPU manufactured on a 40 nm process. It features 640 shading units, a base clock of 400 MHz, and a boost clock of 600 MHz. The card is equipped with 0.5 GB of GDDR3 memory on a 128-bit bus, providing a memory bandwidth of 25.6 GB/s. It supports DirectX 10.1 and OpenGL 3.3, and connects via a PCIe ×16 2.0 interface. Additional features include UVD2 for video decoding and PowerPlay 7.0 for power management.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV740 |
| Process node unverified | 40 nm |
| Shading units unverified | 640 |
| Base clock unverified | 400 MHz |
| Boost clock unverified | 600 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 25.6 GB/s |
| Bus interface unverified | PCIe ×16 2.0 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2009-03-03 |
| Release year unverified | 2009 |
| Notes unverified | UVD2, PowerPlay 7.0 |
