AMD · 2010
AMD Mobility Radeon HD 565v
The AMD Mobility Radeon HD 565v is a mid-range mobile graphics card released in 2010, based on the TeraScale architecture.
The AMD Mobility Radeon HD 565v is a mobile graphics card introduced on May 5, 2010. It uses the TeraScale architecture and is built on the RV730 GPU chip with a 55 nm process node. The card features 320 shading units and a base clock speed of 675 MHz. It supports DirectX 10.1 and OpenGL 3.3. Memory configuration includes 1 GB of DDR2, DDR3, or GDDR3 memory on a 128-bit bus, providing a memory bandwidth of 25.6 GB/s. The card has a maximum power consumption (TDP) of 20 W and connects via a PCIe ×16 2.0 interface. It was designed for use in laptops and other mobile systems requiring moderate graphics performance.
Benchmarks
| PassMark G3D Mark | 353 |
|---|---|
| PassMark G2D Mark | 318 |
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV730 |
| Process node unverified | 55 nm |
| Shading units unverified | 320 |
| Base clock unverified | 675 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | DDR2, DDR3, GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 25.6 GB/s |
| Board power (TDP) unverified | 20 W |
| Bus interface unverified | PCIe ×16 2.0 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2010-05-05 |
| Release year unverified | 2010 |
