AMD · 2008
AMD Radeon 3100 Graphics
The AMD Radeon 3100 Graphics is an integrated graphics processor released in 2008, based on the TeraScale architecture and RV610 chip.
The AMD Radeon 3100 Graphics is an integrated graphics solution from AMD, introduced on January 23, 2008. It utilizes the TeraScale architecture and features the RV610 GPU chip manufactured on a 55 nm process. The graphics processor includes 40 shading units and operates at a base clock speed of 350 MHz. Memory is shared with the system via HyperTransport (HT) 3.0 bus, with a maximum allocated memory of 0.5 GB and a memory bandwidth of 20.8 GB/s. The board has a thermal design power (TDP) of 35 W. This GPU is designed for basic computing tasks and light multimedia use, typically integrated into motherboards or low-power systems of the era.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV610 |
| Process node unverified | 55 nm |
| Shading units unverified | 40 |
| Base clock unverified | 350 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | System (HT) |
| Memory bandwidth unverified | 20.8 GB/s |
| Board power (TDP) unverified | 35 W |
| Bus interface unverified | HT 3.0 |
| Release date unverified | 2008-01-23 |
| Release year unverified | 2008 |
