AMD · 2007
AMD Radeon E2400
The AMD Radeon E2400 is a low-power graphics card for embedded systems, released in 2007.
The AMD Radeon E2400 is a graphics card based on the Terascale 1 architecture, featuring the RV610 GPU chip built on a 65 nm process node. It includes 40 shading units and operates at a base clock of 600 MHz. The card is equipped with 0.128 GB of GDDR3 memory on a 64-bit bus, providing a memory bandwidth of 11.2 GB/s. With a board power (TDP) of only 7 W, it is designed for low-power embedded applications. It supports DirectX 10.0 and OpenGL 3.3, and offers two DVI display outputs. The card connects via a PCIe 1.1 ×16 bus interface.
Specifications
| Architecture unverified | Terascale 1 |
|---|---|
| GPU chip unverified | RV610 |
| Process node unverified | 65 nm |
| Shading units unverified | 40 |
| Base clock unverified | 600 MHz |
| Memory size unverified | 0.128 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 11.2 GB/s |
| Board power (TDP) unverified | 7 W |
| Bus interface unverified | PCIe 1.1 ×16 |
| Display outputs unverified | 2× DVI |
| DirectX support unverified | 10.0 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2007-06 |
| Release year unverified | 2007 |
