AMD · 2011
AMD Radeon E6460
The AMD Radeon E6460 is a low-power embedded graphics card from 2011, based on the Terascale 2 architecture.
The AMD Radeon E6460 is an embedded graphics card released in April 2011. It uses the Terascale 2 architecture and the Caicos GPU chip built on a 40 nm process. The card features 160 shading units, a base clock of 600 MHz, and 0.5 GB of GDDR5 memory on a 64-bit bus, providing a memory bandwidth of 25.6 GB/s. It has a board power (TDP) of 19 W and connects via PCIe 2.1 ×16. Display outputs include 4× miniDP/DVI, 2× DVI and DP. It supports DirectX 11.2 and OpenGL 4.1, but not Vulkan.
Specifications
| Architecture unverified | Terascale 2 |
|---|---|
| GPU chip unverified | Caicos |
| Process node unverified | 40 nm |
| Shading units unverified | 160 |
| Base clock unverified | 600 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 25.6 GB/s |
| Board power (TDP) unverified | 19 W |
| Bus interface unverified | PCIe 2.1 ×16 |
| Display outputs unverified | 4× miniDP/DVI, 2× DVI and DP |
| DirectX support unverified | 11.2 |
| Vulkan support unverified | N/a |
| OpenGL support unverified | 4.1 |
| Release date unverified | 2011-04 |
| Release year unverified | 2011 |
