AMD · 2015
AMD Radeon E6465
The AMD Radeon E6465 is a low-power embedded graphics card released in 2015, based on the Terascale 2 architecture.
The AMD Radeon E6465 is a graphics card designed for embedded systems, released in September 2015. It uses the Terascale 2 architecture with a Caicos GPU chip manufactured on a 40 nm process. The card features 160 shading units running at a base clock of 600 MHz, and is equipped with 2 GB of GDDR5 memory on a 64-bit bus, providing a memory bandwidth of 25.6 GB/s. With a board power (TDP) of only 20 W, it is suitable for low-power applications. The card supports DirectX 11.2 and OpenGL up to 4.4, but does not support Vulkan. It connects via PCIe 2.1 ×16 and offers multiple display output configurations: either 4× miniDP or 2× DP for PCIe versions, or 4× DP/HDMI/DVI for MXM Type A modules.
Specifications
| Architecture unverified | Terascale 2 |
|---|---|
| GPU chip unverified | Caicos |
| Process node unverified | 40 nm |
| Shading units unverified | 160 |
| Base clock unverified | 600 MHz |
| Memory size unverified | 2 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 25.6 GB/s |
| Board power (TDP) unverified | 20 W |
| Bus interface unverified | PCIe 2.1 ×16 |
| Display outputs unverified | 4× miniDP, 2× DP, 4× DP/HDMI/DVI |
| DirectX support unverified | 11.2 |
| Vulkan support unverified | N/a |
| OpenGL support unverified | 4.1 (up to 4.4) |
| Release date unverified | 2015-09 |
| Release year unverified | 2015 |
| Notes unverified | PCIe (4× miniDP or 2× DP), or MXM Type A (4× DP/HDMI/DVI) |
