AMD · 2014
AMD Radeon E8860
The AMD Radeon E8860 is a graphics card released in 2014, based on the GCN 1 architecture with a Venus GPU chip.
The AMD Radeon E8860 is a graphics card released in January 2014, built on the Graphics Core Next (GCN) 1 architecture. It features the Venus GPU chip manufactured on a 28 nm process. The card includes 640 shading units and operates at a base clock of 625 MHz. It is equipped with 2 GB of GDDR5 memory on a 128-bit bus, providing a memory bandwidth of 72 GB/s. The board power (TDP) is rated at 37 W. It connects via a PCIe 3.0 ×16 bus interface and offers multiple display outputs including miniDP, DVI+miniDP, and DP/HDMI/DVI. The card supports DirectX 12.0, Vulkan 1.0, and OpenGL 4.5.
Specifications
| Architecture unverified | GCN 1 |
|---|---|
| GPU chip unverified | Venus |
| Process node unverified | 28 nm |
| Shading units unverified | 640 |
| Base clock unverified | 625 MHz |
| Memory size unverified | 2 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 72 GB/s |
| Board power (TDP) unverified | 37 W |
| Bus interface unverified | PCIe 3.0 ×16 |
| Display outputs unverified | miniDP, DVI+miniDP, DP/HDMI/DVI |
| DirectX support unverified | 12.0 |
| Vulkan support unverified | 1.0 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2014-01 |
| Release year unverified | 2014 |
