AMD · 2015
AMD Radeon E8870
The AMD Radeon E8870 is a graphics card for embedded systems, released in September 2015. It features 768 shading units and 4 GB of GDDR5 memory.
The AMD Radeon E8870 is a graphics card designed for embedded applications, released in September 2015. It is based on the GCN 2 architecture with a Saturn GPU chip manufactured on a 28 nm process. The card features 768 shading units operating at a base clock of 1000 MHz. It comes with 4 GB of GDDR5 memory on a 128-bit bus, providing a memory bandwidth of 96 GB/s. The board power (TDP) is rated at 75 W. It uses a PCIe 3.0 ×16 bus interface and offers display outputs including 4× DisplayPort and 6× DP/HDMI/DVI. It supports DirectX 12.0, Vulkan 1.0, and OpenGL 4.5.
Specifications
| Architecture unverified | GCN 2 |
|---|---|
| GPU chip unverified | Saturn |
| Process node unverified | 28 nm |
| Shading units unverified | 768 |
| Base clock unverified | 1000 MHz |
| Memory size unverified | 4 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 96 GB/s |
| Board power (TDP) unverified | 75 W |
| Bus interface unverified | PCIe 3.0 ×16 |
| Display outputs unverified | 4× DP, 6× DP/HDMI/DVI |
| DirectX support unverified | 12.0 |
| Vulkan support unverified | 1.0 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2015-09 |
| Release year unverified | 2015 |
