AMD · 2019
AMD Radeon E9390
The AMD Radeon E9390 is a graphics card for embedded systems, released in October 2019. It features 8 GB GDDR5 memory and a TDP of 75 W.
The AMD Radeon E9390 is a graphics card designed for embedded applications, launched in October 2019. It is based on the GCN 4 architecture with a Polaris10 GPU chip manufactured on a 14 nm process. The card features 1792 shading units, a base clock of 1086 MHz, and 8 GB of GDDR5 memory on a 256-bit bus, providing a memory bandwidth of 160 GB/s. It supports PCIe 3.0 ×16 interface and has four DisplayPort outputs. The board power (TDP) is 75 W, making it suitable for power-constrained systems. It supports DirectX 12.0, Vulkan 1.0, and OpenGL 4.5.
Specifications
| Architecture unverified | GCN 4 |
|---|---|
| GPU chip unverified | Polaris10 |
| Process node unverified | 14 nm |
| Shading units unverified | 1792 |
| Base clock unverified | 1086 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 160 GB/s |
| Board power (TDP) unverified | 75 W |
| Bus interface unverified | PCIe 3.0 ×16 |
| Display outputs unverified | 4× DisplayPort |
| DirectX support unverified | 12.0 |
| Vulkan support unverified | 1.0 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2019-10 |
| Release year unverified | 2019 |
