AMD · 2009
AMD Radeon HD 3610
The AMD Radeon HD 3610 is a graphics card released in 2009, based on the TeraScale architecture with the RV630 PRO chip.
The AMD Radeon HD 3610 is a graphics card released on September 24, 2009. It is built on the TeraScale architecture using the RV630 PRO GPU chip fabricated on a 65 nm process node. The card features 120 shading units and a base clock of 594 MHz. It comes with 0.5 GB of DDR2 memory on a 128-bit bus, providing a memory bandwidth of 12.7 GB/s. The card has a board power (TDP) of 35 W and connects via a PCIe 1.0 ×16 interface. It supports DirectX 10.1 and OpenGL 3.3.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV630 PRO |
| Process node unverified | 65 nm |
| Shading units unverified | 120 |
| Base clock unverified | 594 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | DDR2 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 12.7 GB/s |
| Board power (TDP) unverified | 35 W |
| Bus interface unverified | PCIe 1.0 ×16 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2009-09-24 |
| Release year unverified | 2009 |
