AMD · 2009
AMD Radeon HD 4200 Graphics
The AMD Radeon HD 4200 Graphics is an integrated graphics processor released in August 2009, based on the TeraScale architecture.
The AMD Radeon HD 4200 Graphics is an integrated GPU (IGP) launched in August 2009. It uses the TeraScale architecture and is built on a 55 nm process node with the RV620 chip. The GPU features 40 shading units and a base clock of 500 MHz. It supports up to 0.512 GB of DDR2 or DDR3 memory via a 16-bit memory bus, providing a memory bandwidth of 23.4 GB/s. The interface is HT 3.0. It supports DirectX 10.1 and OpenGL 3.3, and includes UVD2 for video decoding. This graphics solution was typically integrated into AMD chipsets for desktop and notebook platforms.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV620 |
| Process node unverified | 55 nm |
| Shading units unverified | 40 |
| Base clock unverified | 500 MHz |
| Memory size unverified | 0.512 GB |
| Memory type unverified | DDR2, DDR3 |
| Memory bus unverified | 16 bit |
| Memory bandwidth unverified | 23.4 GB/s |
| Bus interface unverified | HT 3.0 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2009-08 |
| Release year unverified | 2009 |
| Notes unverified | UVD2 |
