AMD · 2008
AMD Radeon HD 4570
The AMD Radeon HD 4570 is a graphics card released in 2008, based on the TeraScale architecture with the RV710 GPU.
The AMD Radeon HD 4570 is a graphics card released on November 25, 2008. It uses the TeraScale architecture and features the RV710 GPU built on a 55 nm process. The card has 80 shading units and a base clock of 650 MHz. It comes with 1 GB of DDR2 memory on a 64-bit bus, providing a memory bandwidth of 8.00 GB/s. The card has a board power (TDP) of 25 W and connects via PCIe 2.0 ×16. It supports DirectX 10.1 and OpenGL 3.3.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV710 |
| Process node unverified | 55 nm |
| Shading units unverified | 80 |
| Base clock unverified | 650 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | DDR2 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 8.00 GB/s |
| Board power (TDP) unverified | 25 W |
| Bus interface unverified | PCIe 2.0 ×16 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2008-11-25 |
| Release year unverified | 2008 |
