AMD · 2013
AMD Radeon Sky 500
The AMD Radeon Sky 500 is a professional graphics card released in 2013, based on the Graphics Core Next 2 architecture.
The AMD Radeon Sky 500 is a professional graphics card released in 2013. It uses the Graphics Core Next 2 architecture and features the Pitcairn XT GPU chip fabricated on a 28 nm process. The card has 1280 shading units, a base clock of 950 MHz, and 4 GB of GDDR5 memory on a 256-bit bus, providing a memory bandwidth of 153.6 GB/s. It has a board power (TDP) of 150 W and connects via PCIe 3.0 x16. Display output is limited to one DisplayPort. It supports DirectX 12.0 and OpenGL 4.5.
Specifications
| Architecture unverified | Graphics Core Next 2 |
|---|---|
| GPU chip unverified | Pitcairn XT |
| Process node unverified | 28 nm |
| Shading units unverified | 1280 |
| Base clock unverified | 950 MHz |
| Memory size unverified | 4 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 153.6 GB/s |
| Board power (TDP) unverified | 150 W |
| Bus interface unverified | PCIe 3.0 x16 |
| Display outputs unverified | One DisplayPort |
| DirectX support unverified | 12.0 |
| OpenGL support unverified | 4.5 |
| Release year unverified | 2013 |
