NVIDIA · 2014
NVIDIA GeForce 810M
The NVIDIA GeForce 810M is an entry-level mobile graphics card released in 2014, based on the Fermi 2.0 architecture.
The NVIDIA GeForce 810M is a mobile graphics card released in February 2014. It is built on the Fermi 2.0 architecture using the GF117 chip on a 28 nm process. The card features 48 shading units, a base clock of 738 MHz, and a boost clock of 888 MHz. It is equipped with 1 GB of DDR3 memory on a 64-bit bus, providing a memory bandwidth of 14.4 GB/s. The board power (TDP) is 15 W, and it connects via PCIe 2.0 x16. The GeForce 810M supports DirectX 12 and OpenGL 4.5, but does not support Vulkan. It is designed for entry-level laptops and basic computing tasks.
Specifications
| Architecture unverified | Fermi 2.0 |
|---|---|
| GPU chip unverified | GF117 |
| Process node unverified | 28 nm |
| Shading units unverified | 48 |
| Base clock unverified | 738 MHz |
| Boost clock unverified | 888 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | DDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 14.4 GB/s |
| Board power (TDP) unverified | 15 W |
| Bus interface unverified | PCIe 2.0 x16 |
| DirectX support unverified | 12 |
| Vulkan support unverified | n/a |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2014-02 |
| Release year unverified | 2014 |
