NVIDIA GeForce GT 520M
The NVIDIA GeForce GT 520M is a mobile graphics card released in 2011, based on the Fermi 2.0 architecture with a GF119 chip.
The NVIDIA GeForce GT 520M is a mobile graphics card launched on January 5, 2011. It is built on the Fermi 2.0 architecture using the GF119 GPU chip fabricated on a 40 nm process. The card features 48 shading units, a base clock of 740 MHz, and 1 GB of DDR3 memory on a 64-bit bus, providing a memory bandwidth of 12.8 GB/s. It supports DirectX 12 and OpenGL 4.6, and connects via PCIe 2.0 x16. With a TDP of only 12 W, it is designed for low-power laptops. The GT 520M is similar to the desktop GeForce 510/520 series.
Specifications
| Architecture unverified | Fermi 2.0 |
|---|---|
| GPU chip unverified | GF119 |
| Process node unverified | 40 nm |
| Shading units unverified | 48 |
| Base clock unverified | 740 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | DDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 12.8 GB/s |
| Board power (TDP) unverified | 12 W |
| Bus interface unverified | PCIe 2.0 x16 |
| DirectX support unverified | 12 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2011-01-05 |
| Release year unverified | 2011 |
| Notes unverified | Similar to Desktop 510/520 |
