NVIDIA GeForce RTX 2060 Max-Q

The NVIDIA GeForce RTX 2060 Max-Q is a mobile graphics card released on January 29, 2019. It is based on the Turing architecture and uses the TU106 GPU chip fabricated on a 12 nm process. The card features 1920 shading units, 30 ray tracing cores, and 240 Tensor cores. It has a base clock of 975 MHz and a boost clock of 1175 MHz. The memory subsystem includes 6 GB of GDDR6 memory on a 192-bit bus, providing a memory bandwidth of 264 GB/s. The card has a board power (TDP) of 65 W and connects via PCIe 3.0 x16. It supports DirectX 12, Vulkan 1.3, and OpenGL 4.6. This Max-Q variant is designed for thin and light laptops, offering a balance of performance and power efficiency.
