NVIDIA · 2021
NVIDIA GeForce RTX3060 OEM
The NVIDIA GeForce RTX3060 OEM is a graphics card released in 2021 based on the Ampere architecture, featuring 12 GB GDDR6 memory and ray tracing support.
The NVIDIA GeForce RTX3060 OEM is a graphics card released on February 25, 2021, with a launch MSRP of $329. It is built on the Ampere architecture using an 8 nm process node and the GA106-300 GPU chip. The card features 3584 shading units, 28 ray tracing cores, and 112 Tensor/AI cores. It has a base clock of 1320 MHz and a boost clock of 1777 MHz. Memory configuration includes 12 GB of GDDR6 memory on a 192-bit bus, providing a memory bandwidth of 360 GB/s. The card has a TDP of 170 W and requires a single 12-pin power connector. It uses a PCIe 4.0 x16 bus interface and offers display outputs including HDMI 2.1 and DisplayPort 1.4a. It supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6. This OEM version is designed for pre-built systems and may have different specifications compared to the retail model.
Specifications
| Architecture unverified | Ampere |
|---|---|
| GPU chip unverified | GA106-300 |
| Process node unverified | 8 nm |
| Shading units unverified | 3584 |
| Ray tracing cores unverified | 28 |
| Tensor / AI cores unverified | 112 |
| Base clock unverified | 1320 MHz |
| Boost clock unverified | 1777 MHz |
| Memory size unverified | 12 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 192 bit |
| Memory bandwidth unverified | 360 GB/s |
| Board power (TDP) unverified | 170 W |
| Power connectors unverified | 1x 12-pin |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | HDMI 2.1, DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2021-02-25 |
| Release year unverified | 2021 |
| Launch MSRP unverified | 329 USD |
