NVIDIA · 2022
NVIDIA GeForce RTX3060 Ti GDDR6X
The NVIDIA GeForce RTX 3060 Ti GDDR6X is a mid-range graphics card released in October 2022, based on the Ampere architecture.
The NVIDIA GeForce RTX 3060 Ti GDDR6X is a mid-range graphics card released on October 19, 2022, with a launch MSRP of $399 USD. It is based on the Ampere architecture and uses the GA104-202-A1 GPU chip fabricated on an 8 nm process node. The card features 4864 shading units, 38 ray tracing cores, and 152 tensor cores. Its base clock is 1410 MHz with a boost clock of 1665 MHz. It comes with 8 GB of GDDR6X memory on a 256-bit bus, providing a memory bandwidth of 608.3 GB/s. The board power (TDP) is 225 W, and it requires a single 12-pin power connector. The card supports PCIe 4.0 x16 interface and offers display outputs including one HDMI 2.1 and three DisplayPort 1.4a. It supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6.
Specifications
| Architecture unverified | Ampere |
|---|---|
| GPU chip unverified | GA104-202-A1 |
| Process node unverified | 8 nm |
| Shading units unverified | 4864 |
| Ray tracing cores unverified | 38 |
| Tensor / AI cores unverified | 152 |
| Base clock unverified | 1410 MHz |
| Boost clock unverified | 1665 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR6X |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 608.3 GB/s |
| Board power (TDP) unverified | 225 W |
| Power connectors unverified | 1x 12-pin |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | 1x HDMI 2.1, 3x DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2022-10-19 |
| Release year unverified | 2022 |
| Launch MSRP unverified | 399 USD |
