NVIDIA GeForce RTX5060 Ti 16 GB
The NVIDIA GeForce RTX 5060 Ti 16 GB is a mid-range graphics card based on the Blackwell architecture, released in April 2025.
The NVIDIA GeForce RTX 5060 Ti 16 GB is a mid-range graphics card built on the Blackwell architecture, featuring the GB206-300-A1 GPU on a 4 nm process. It includes 4608 shading units, 36 ray tracing cores, and 144 Tensor/AI cores. The card operates at a base clock of 2407 MHz and a boost clock of 2572 MHz. It is equipped with 16 GB of GDDR7 memory on a 128-bit bus, providing a memory bandwidth of 448 GB/s. The board power (TDP) is 180 W, requiring a single 16-pin power connector. It connects via PCIe 5.0 x8 and offers one HDMI 2.1b and three DisplayPort 2.1b outputs. The card supports DirectX 12 Ultimate, Vulkan 1.4, and OpenGL 4.6. It was released on April 16, 2025, with a launch MSRP of 429 USD.
Specifications
| Architecture unverified | Blackwell |
|---|---|
| GPU chip unverified | GB206-300-A1 |
| Process node unverified | 4 nm |
| Shading units unverified | 4608 |
| Ray tracing cores unverified | 36 |
| Tensor / AI cores unverified | 144 |
| Base clock unverified | 2407 MHz |
| Boost clock unverified | 2572 MHz |
| Memory size unverified | 16 GB |
| Memory type unverified | GDDR7 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 448 GB/s |
| Board power (TDP) unverified | 180 W |
| Power connectors unverified | 1x 16-pin |
| Bus interface unverified | PCIe 5.0 x8 |
| Display outputs unverified | 1x HDMI 2.1b, 3x DisplayPort 2.1b |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.4 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2025-04-16 |
| Release year unverified | 2025 |
| Launch MSRP unverified | 429 USD |
