NVIDIA · 2003
NVIDIA NVS 280
The NVIDIA NVS 280 is a professional graphics card released in 2003, based on the Rankine architecture.
The NVIDIA NVS 280 is a professional graphics card released on October 28, 2003. It is built on the Rankine architecture using the NV34GL GPU on a 150 nm process. The card features 4 shading units, a base clock of 275 MHz, and 0.064 GB of DDR memory on a 128-bit bus, providing a memory bandwidth of 8.0 GB/s. It supports DirectX 9.0 and OpenGL 1.5. The card has a TDP of 13 W and is available with PCIe x16, AGP 8×, or PCI bus interfaces. Display output is via a single DMS-59 connector.
Specifications
| Architecture unverified | Rankine |
|---|---|
| GPU chip unverified | NV34GL |
| Process node unverified | 150 nm |
| Shading units unverified | 4 |
| Base clock unverified | 275 MHz |
| Memory size unverified | 0.064 GB |
| Memory type unverified | DDR |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 8.0 GB/s |
| Board power (TDP) unverified | 13 W |
| Bus interface unverified | PCIe x16/AGP 8× / PCI |
| Display outputs unverified | DMS-59 |
| DirectX support unverified | 9.0 |
| OpenGL support unverified | 1.5 |
| Release date unverified | 2003-10-28 |
| Release year unverified | 2003 |
| Notes unverified | DMS-59 |
