NVIDIA · 2004
NVIDIA NVS 400
The NVIDIA NVS 400 is a multi-display graphics card released in 2004, featuring dual NV17 GPUs for up to four displays.
The NVIDIA NVS 400 is a professional multi-display graphics card released on July 16, 2004. It uses two NV17 GPU chips (architecture 2× NV17) manufactured on a 150 nm process. The card has 4 shading units and a base clock of 220 MHz. It comes with 128 MB of DDR memory on a 256-bit bus, providing 22.0 GB/s memory bandwidth. The board power (TDP) is 18 W. It connects via a PCI bus and outputs video through two LFH-60 connectors. It supports DirectX 7 and OpenGL 1.2.
Specifications
| Architecture unverified | 2× NV17 |
|---|---|
| GPU chip unverified | NV17 |
| Process node unverified | 150 nm |
| Shading units unverified | 4 |
| Base clock unverified | 220 MHz |
| Memory size unverified | 0.128 GB |
| Memory type unverified | DDR |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 22.0 GB/s |
| Board power (TDP) unverified | 18 W |
| Bus interface unverified | PCI |
| Display outputs unverified | 2× LFH-60 |
| DirectX support unverified | 7 |
| OpenGL support unverified | 1.2 |
| Release date unverified | 2004-07-16 |
| Release year unverified | 2004 |
