NVIDIA NVS 5100M
The NVIDIA NVS 5100M is a professional mobile graphics card released in 2011, based on the Tesla 2.0 architecture.
The NVIDIA NVS 5100M is a professional mobile graphics card released on February 22, 2011. It is built on the Tesla 2.0 architecture using the GT216M GPU chip manufactured on a 40 nm process. The card features 48 shading units with a base clock of 550 MHz. It comes with 1 GB of GDDR3 memory on a 128-bit bus, providing a memory bandwidth of 25.6 GB/s. The NVS 5100M has a board power (TDP) of 35 W and uses a PCIe 2.0 x16 bus interface. It supports DirectX 10.1 and OpenGL 3.3. This card is designed for professional workstation applications, typically used in mobile workstations for CAD, DCC, and other professional graphics tasks.
Specifications
| Architecture unverified | Tesla 2.0 |
|---|---|
| GPU chip unverified | GT216M |
| Process node unverified | 40 nm |
| Shading units unverified | 48 |
| Base clock unverified | 550 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 25.6 GB/s |
| Board power (TDP) unverified | 35 W |
| Bus interface unverified | PCIe 2.0 x16 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2011-02-22 |
| Release year unverified | 2011 |
