NVIDIA Quadro 500M
The NVIDIA Quadro 500M is a professional mobile graphics card released in 2011, based on the Fermi architecture.
The NVIDIA Quadro 500M is a professional mobile graphics card released on February 22, 2011. It is built on the Fermi architecture using the GF108 GPU chip fabricated on a 40 nm process. The card features 96 shading units, a base clock of 700 MHz, and 1 GB of DDR3 memory on a 128-bit bus, providing a memory bandwidth of 28.8 GB/s. It supports DirectX 11.0 and OpenGL 4.5, and has a board power (TDP) of 35 W. The card connects via a PCIe 2.0 x16 interface. It is designed for use in professional mobile workstations, offering certified performance for CAD, DCC, and visualization applications.
Specifications
| Architecture unverified | Fermi |
|---|---|
| GPU chip unverified | GF108 |
| Process node unverified | 40 nm |
| Shading units unverified | 96 |
| Base clock unverified | 700 MHz |
| Memory size unverified | 1 GB |
| Memory type unverified | DDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 28.8 GB/s |
| Board power (TDP) unverified | 35 W |
| Bus interface unverified | PCIe 2.0 x16 |
| DirectX support unverified | 11.0 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2011-02-22 |
| Release year unverified | 2011 |
