NVIDIA · 2006
NVIDIA Quadro FX 560M
The NVIDIA Quadro FX 560M is a mobile professional graphics card released in 2006, based on the Curie architecture with a G73GLM chip.
The NVIDIA Quadro FX 560M is a mobile graphics card for professional workstations, released on April 20, 2006. It uses the Curie architecture and the G73GLM GPU chip built on a 90 nm process. The card features 5 shading units, a base clock of 500 MHz, and 0.5 GB of GDDR3 memory on a 128-bit bus, providing a memory bandwidth of 19.2 GB/s. It supports DirectX 9.0c and OpenGL 2.1, and has a TDP of 35 W. The card connects via PCIe 1.0 x16. It is likely based on the GeForce 7600GS.
Specifications
| Architecture unverified | Curie |
|---|---|
| GPU chip unverified | G73GLM |
| Process node unverified | 90 nm |
| Shading units unverified | 5 |
| Base clock unverified | 500 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 19.2 GB/s |
| Board power (TDP) unverified | 35 W |
| Bus interface unverified | PCIe 1.0 x16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.1 |
| Release date unverified | 2006-04-20 |
| Release year unverified | 2006 |
| Notes unverified | 7600GS based? |
