NVIDIA · 2017
NVIDIA Quadro M2200 Mobile
The NVIDIA Quadro M2200 Mobile is a professional mobile graphics card released in 2017, based on the Maxwell architecture.
The NVIDIA Quadro M2200 Mobile is a professional mobile graphics card introduced in 2017. It is built on the Maxwell architecture using the GM206 chip on a 28 nm process. The card features 1024 shading units with a base clock of 695 MHz and a boost clock of 1037 MHz. It is equipped with 4 GB of GDDR5 memory on a 128-bit bus, providing a memory bandwidth of 88.1 GB/s. The board power (TDP) is rated at 55 W, and it connects via PCIe 3.0 x16. It supports DirectX 12.1 and OpenGL 4.5. This card is designed for mobile workstations, intended for use with professional applications such as CAD and DCC.
Specifications
| Architecture unverified | Maxwell |
|---|---|
| GPU chip unverified | GM206 |
| Process node unverified | 28 nm |
| Shading units unverified | 1024 |
| Base clock unverified | 695 MHz |
| Boost clock unverified | 1037 MHz |
| Memory size unverified | 4 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 88.1 GB/s |
| Board power (TDP) unverified | 55 W |
| Bus interface unverified | PCIe 3.0 x16 |
| DirectX support unverified | 12.1 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2017-01-11 |
| Release year unverified | 2017 |
