NVIDIA · 2016
NVIDIA Quadro M5500 Mobile
The NVIDIA Quadro M5500 Mobile is a professional mobile graphics card for laptops, released in 2016.
The NVIDIA Quadro M5500 Mobile is a professional mobile graphics card based on the Maxwell 2.0 architecture, featuring the GM204 GPU chip built on a 28 nm process. It offers 2048 shading units, with a base clock of 861 MHz and a boost clock of 1140 MHz. The card is equipped with 8 GB of GDDR5 memory on a 256-bit bus, providing a memory bandwidth of 211.4 GB/s. It has a TDP of 150 W and connects via PCIe 3.0 x16. The Quadro M5500 supports DirectX 12.1 and OpenGL 4.5. It is designed for use in high-end mobile workstations, suitable for CAD, 3D modeling, and other professional applications.
Specifications
| Architecture unverified | Maxwell 2.0 |
|---|---|
| GPU chip unverified | GM204 |
| Process node unverified | 28 nm |
| Shading units unverified | 2048 |
| Base clock unverified | 861 MHz |
| Boost clock unverified | 1140 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 211.4 GB/s |
| Board power (TDP) unverified | 150 W |
| Bus interface unverified | PCIe 3.0 x16 |
| DirectX support unverified | 12.1 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2016-04-08 |
| Release year unverified | 2016 |
