NVIDIA Quadro P2200
The NVIDIA Quadro P2200 is a professional graphics card released in 2019, based on the Pascal architecture and GP106 chip.
The NVIDIA Quadro P2200 is a professional graphics card released on June 10, 2019. It is built on the Pascal architecture using the GP106 GPU chip manufactured on a 16 nm process. The card features 1280 shading units with a base clock of 1000 MHz and a boost clock of 1493 MHz. It comes with 5 GB of GDDR5X memory on a 160-bit bus, providing a memory bandwidth of 200 GB/s. The board power (TDP) is 75 W, and it connects via PCIe 3.0 x16. Display outputs include four DisplayPort 1.4 connectors. It supports DirectX 12.1, Vulkan 1.3, and OpenGL 4.6. The Quadro P2200 is designed for workstation use, compatible with systems requiring a PCIe 3.0 x16 slot and a 75 W power budget.
Specifications
| Architecture unverified | Pascal |
|---|---|
| GPU chip unverified | GP106 |
| Process node unverified | 16 nm |
| Shading units unverified | 1280 |
| Base clock unverified | 1000 MHz |
| Boost clock unverified | 1493 MHz |
| Memory size unverified | 5 GB |
| Memory type unverified | GDDR5X |
| Memory bus unverified | 160 bit |
| Memory bandwidth unverified | 200 GB/s |
| Board power (TDP) unverified | 75 W |
| Bus interface unverified | PCIe 3.0 x16 |
| Display outputs unverified | Four DisplayPort 1.4 |
| DirectX support unverified | 12.1 |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2019-06-10 |
| Release year unverified | 2019 |
