NVIDIA · 2002
NVIDIA Quadro4 500 Go GL
The NVIDIA Quadro4 500 Go GL is a mobile professional graphics card released in 2002, based on the GeForce4 Go GPU.
The NVIDIA Quadro4 500 Go GL is a mobile graphics card designed for professional workstations, released on April 23, 2002. It is based on the NV17 architecture and uses the GeForce4 Go GPU manufactured on a 150 nm process. The card features a dynamic core clock ranging from 66 to 220 MHz and a core voltage of 1.35 V. It is equipped with 0.0625 GB of DDR memory on a 128-bit bus, providing a memory bandwidth of 7.0 GB/s. The Quadro4 500 Go GL supports DirectX 7.0 and OpenGL 1.2, and connects via AGP 4x or 8x interfaces. According to NVIDIA brochures, it uses DDR SDRAM.
Specifications
| Architecture unverified | NV17 |
|---|---|
| GPU chip unverified | GeForce4 Go |
| Process node unverified | 150 nm |
| Base clock unverified | 220 MHz |
| Memory size unverified | 0.0625 GB |
| Memory type unverified | DDR |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 7.0 GB/s |
| Bus interface unverified | AGP 4x,8x |
| DirectX support unverified | 7.0 |
| OpenGL support unverified | 1.2 |
| Release date unverified | 2002-04-23 |
| Release year unverified | 2002 |
| Notes unverified | Based on the GeForce4 Go, dynamic core clock 66–220 MHz, core voltage 1.35 V, uses DDR SDRAM according to Nvidia brochures |
