NVIDIA RTX PRO 500 Blackwell Mobile
The NVIDIA RTX PRO 500 Blackwell Mobile is a professional mobile GPU based on the Blackwell architecture, designed for workstations.
The NVIDIA RTX PRO 500 Blackwell Mobile is a professional graphics card for mobile workstations, built on the Blackwell architecture using the GB207 chip on a 4 nm process. It features 1792 shading units, 56 ray tracing cores, and 56 Tensor/AI cores, with base and boost clocks of 2235 MHz and 2520 MHz respectively. The card is equipped with 6 GB of GDDR7 memory on a 96-bit bus, providing a memory bandwidth of 336 GB/s. It has a board power (TDP) of 35 W and connects via PCIe 5.0 x16. It supports DirectX 12.2, Vulkan 1.4, and OpenGL 4.6. The release date is TBA.
Specifications
| Architecture unverified | Blackwell |
|---|---|
| GPU chip unverified | GB207 |
| Process node unverified | 4 nm |
| Shading units unverified | 1792 |
| Ray tracing cores unverified | 56 |
| Tensor / AI cores unverified | 56 |
| Base clock unverified | 2235 MHz |
| Boost clock unverified | 2520 MHz |
| Memory size unverified | 6 GB |
| Memory type unverified | GDDR7 |
| Memory bus unverified | 96 bit |
| Memory bandwidth unverified | 336 GB/s |
| Board power (TDP) unverified | 35 W |
| Bus interface unverified | PCIe 5.0 x16 |
| DirectX support unverified | 12.2 |
| Vulkan support unverified | 1.4 |
| OpenGL support unverified | 4.6 |
| Release date unverified | TBA |
