AMD · 2008
Radeon HD 3470
The Radeon HD 3470 is an entry-level graphics card by AMD, released in 2008, based on the TeraScale architecture.
The Radeon HD 3470 is an entry-level graphics card from AMD, released on January 23, 2008. It is built on the TeraScale architecture using the RV620 PRO GPU chip manufactured on a 55 nm process. The card features 40 shading units and a base clock of 800 MHz. It comes with 0.256 GB of memory, available in DDR2 or GDDR3 types, on a 64-bit memory bus, providing a memory bandwidth of 15.2 GB/s. The card has a board power (TDP) of 30 W and connects via a PCIe 2.0 ×16 interface. It supports DirectX 10.1 and OpenGL 3.3. This card is suitable for basic computing tasks and light multimedia use, and can be paired with other components from the same era.
Benchmarks
| PassMark G3D Mark | 90 |
|---|---|
| PassMark G2D Mark | 95 |
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV620 PRO |
| Process node unverified | 55 nm |
| Shading units unverified | 40 |
| Base clock unverified | 800 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | DDR2, GDDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 15.2 GB/s |
| Board power (TDP) unverified | 30 W |
| Bus interface unverified | PCIe 2.0 ×16 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2008-01-23 |
| Release year unverified | 2008 |
