ATI · 2006
Radeon X1300 XT
The Radeon X1300 XT is a graphics card by ATI released in August 2006, based on the RV530 chip and TeraScale architecture.
The Radeon X1300 XT is a graphics card from ATI, launched on August 12, 2006, with a launch MSRP of 89 USD. It is built on the TeraScale architecture using the RV530 GPU chip fabricated on a 90 nm process. The card features 12 shading units and a base clock of 500 MHz. It comes with 256 MB of DDR2 memory on a 128-bit bus, providing a memory bandwidth of 8.0 GB/s. The card has a board power (TDP) of 22 W and connects via a PCIe ×16 interface. It supports DirectX 9.0c and OpenGL 2.1. This entry-level card was intended for budget-conscious users and is compatible with motherboards having a PCIe ×16 slot.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV530 |
| Process node unverified | 90 nm |
| Shading units unverified | 12 |
| Base clock unverified | 500 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | DDR2 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 8.0 GB/s |
| Board power (TDP) unverified | 22 W |
| Bus interface unverified | PCIe ×16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.1 |
| Release date unverified | 2006-08-12 |
| Release year unverified | 2006 |
| Launch MSRP unverified | 89 USD |
