ATI · 2005
Radeon X1600
The Radeon X1600 is a graphics card released by ATI in 2005, based on the 90 nm RV530 GPU with 12 shading units.
The Radeon X1600 is a graphics card introduced by ATI on October 10, 2005. It is built on the RV530 GPU fabricated on a 90 nm process node. The card was available with either an AGP 8× or PCIe ×16 bus interface. It features a base clock of 500 MHz and 12 shading units. Memory is accessed via a 128-bit bus, using DDR2 or GDDR3 memory, providing a bandwidth of 12.48 GB/s. The card has a typical board power (TDP) of 41 W. It supports DirectX 9.0c and OpenGL 2.1. The Radeon X1600 was designed for mid-range desktop systems of its era.
Benchmarks
| PassMark G3D Mark | 49 |
|---|---|
| PassMark G2D Mark | 209 |
Specifications
| GPU chip unverified | RV530 |
|---|---|
| Process node unverified | 90 nm |
| Shading units unverified | 12 |
| Base clock unverified | 500 MHz |
| Memory type unverified | DDR2, GDDR3 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 12.48 GB/s |
| Board power (TDP) unverified | 41 W |
| Bus interface unverified | AGP 8×, PCIe ×16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.1 |
| Release date unverified | 2005-10-10 |
| Release year unverified | 2005 |
